Voltronic Power Galleon III 3P/3P 30K~60K Rack

Voltronic Galleon III 3P/3P 30K~60K Rack

Discover the Voltronic Power Galleon III 3P/3P 30K~60K Rack with 3x 380/400/415 VAC nominal voltage and precise AC voltage regulation.

  • Voltage: 3x 380-415 VAC (3P)
  • Voltage Range: 190-520 VAC (3P)
  • Power Factor: >= 0.99
AED 80,000incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Galleon III 3P/3P 30K~60K Rack features

True double-conversion

LCD screen auto-rotation with Rack

LCD screen auto-rotation with Rack position (only for 30KL & 40KL models)

DSP technology guarantees high performance

Output power factor 1

Active power factor correction in

Active power factor correction in all phases

50Hz/60Hz frequency converter mode

ECO mode operation for energy

ECO mode operation for energy saving (ECO)

Emergency power off function (EPO)

Generator compatible

Supports dual AC inputs

3-stage extendable charging design for

3-stage extendable charging design for optimized battery performance

Adjustable battery numbers for long-run

Adjustable battery numbers for long-run model

Parallel operation with common battery

About the Voltronic Galleon III 3P/3P 30K~60K Rack

The Voltronic Power Galleon III 3P/3P 30K~60K Rack is a robust online UPS solution designed for critical applications. With a nominal voltage of 3x 380/400/415 VAC and precise AC voltage regulation, it ensures reliable power delivery even under demanding conditions. Ideal for data centers, industrial facilities, and telecommunications, the Galleon III provides seamless power protection and stability.

Specifications last updated 27 March 2026

Voltronic Galleon III 3P/3P 30K~60K Rack full specifications

Electrical

Nominal Voltage3x 380/400/415 VAC (3Ph+N)
Voltage Range190-520 VAC (3-phase) @ 50% load, 305-478 VAC (3-phase) @ 100% load
Frequency46-54 Hz or 56-64 Hz
Power Factor≥ 0.99 @ 100% load
Output Voltage3x 380/400/415 VAC (3Ph+N)
AC Voltage Regulation (Batt. Mode)± 1%
Frequency Range (Synchronized Range)46-54 Hz or 56-64 Hz
Frequency Range (Batt. Mode)50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
Current Crest Ratio3:1 (max.)
Harmonic Distortion≤ 2 % THD (Linear Load); ≤ 5 % THD (Non-linear Load)
Transfer Time AC mode to Battery mode0 ms
Transfer Time Inverter to Bypass0 ms
Waveform (Batt. Mode)Pure Sinewave
Overload100-110% for 60 min, 110-125% for 10 min, 125%-150% for 1 min; >150% immediately
AC Mode95.5%
ECO Mode98.5%
Battery TypeDepending on the applications
Battery Numbers±16 ~20 (Adjustable)
Charging Current (max.)1A~12A (Adjustable) / 1A~12A (Adjustable) / 1A~18A (Adjustable)
Charging Voltage+/-(13.65V x N (N=16~20))
Smart RS-232/USBSupports Windows® family, Linux and MAC
Optional SNMPPower management from SNMP manager and web browser
Battery Mode94.5%

Mechanical

Dimension, D x W x H (mm)680 x 438 x 133 [3U] / 680 x 438 x 133 [3U] / 797 x 438 x 176 [4U]
Net Weight (Kgs)32 / 34 / 45
Weight32 / 34 / 45

Environmental

Operating Temperature0-40°C
Operating Humidity< 95 % and non-condensing
Noise LevelLess than 65dB @ 1 Meter / Less than 65dB @ 1 Meter / Less than 70dB @ 1 Meter
