Voltronic Power Galleon One RT

Voltronic Galleon One RT

Discover the Galleon One RT by Voltronic Power, an online UPS with nominal voltage options from 100 to 240 VAC and precise voltage regulation.

  • Nominal Voltage: 100-240 VAC
  • Voltage Range: 85-300 VAC
  • Power Factor: > 0.99
AED 7,000incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Galleon One RT features

True double-conversion

Output power factor 1

Built-in 2.8” touch LCD for

Built-in 2.8” touch LCD for comprehensive UPS status

Output voltage regulation < 1%

50Hz/60Hz frequency converter mode

Programmable power management outlets

Hot swappable battery design

ECO mode energy saving

Provides overload, battery cut-off protection

Provides overload, battery cut-off protection and surge immunity by MOV for full time equipment protection

High power factor charger up

High power factor charger up to 8A/12A capacity with very low ripple current when charging battery

Low input THDi to reduce

Low input THDi to reduce power system pollution

Adjustable charging current via LCD

Adjustable charging current via LCD panel

Optional HID Power Device USB

Optional HID Power Device USB Port

About the Voltronic Galleon One RT

The Galleon One RT by Voltronic Power is a cutting-edge online UPS designed to deliver reliable power protection. With a wide range of nominal voltage options and precise voltage regulation, it ensures your critical systems remain operational under any conditions. Ideal for data centers, telecommunications, and industrial applications, the Galleon One RT provides seamless power backup and protection against voltage fluctuations.

Specifications last updated 27 March 2026

Voltronic Galleon One RT full specifications

Electrical

Nominal Voltage100/110/115/120/127 VAC or 200/208/220/230/240 VAC / 100/110/115/120/127 VAC or 200/208/220/230/240 VAC / 100/110/115/120/127 VAC or 200/208/220/230/240 VAC / 100/110/115/120/127 VAC or 200/208/220/230/240 VAC / 208/220/230/240 VAC / 208/220/230/240 VAC
Voltage Range85-150 VAC ± 5% or 110-300 VAC ± 5% @ 50% load / 85-150 VAC ± 5% or 110-300 VAC ± 5% @ 50% load / 85-150 VAC ± 5% or 110-300 VAC ± 5% @ 50% load / 85-150 VAC ± 5% or 110-300 VAC ± 5% @ 50% load / 110-300VAC ± 3% @ 50% load; 176-300VAC ± 3% @ 100% load / 110-300VAC ± 3% @ 50% load; 176-300VAC ± 3% @ 100% load
Frequency Range40 Hz ~ 70 Hz / 40 Hz ~ 70 Hz / 40 Hz ~ 70 Hz / 40 Hz ~ 70 Hz / 46~54 Hz or 56~64 Hz / 46~54 Hz or 56~64 Hz
Power Factor> 0.99 @ nominal voltage (100% load) / > 0.99 @ nominal voltage (100% load) / > 0.99 @ nominal voltage (100% load) / > 0.99 @ nominal voltage (100% load) / ≥ 0.99 @ full load / ≥ 0.99 @ full load
Output Voltage100*/110*/115*/120*/127 VAC or 200*/208/220/230/240 VAC / 100*/110*/115*/120*/127 VAC or 200*/208/220/230/240 VAC / 100*/110*/115*/120*/127 VAC or 200*/208/220/230/240 VAC / 100*/110*/115*/120*/127 VAC or 200*/208/220/230/240 VAC / 208*/220/230/240 VAC / 208*/220/230/240 VAC
AC Voltage Regulation± 1% / ± 1% / ± 1% / ± 1% / ± 1% / ± 1%
Frequency Range (Synchronized Range)57 ~ 63 Hz or 47 ~ 53 Hz / 57 ~ 63 Hz or 47 ~ 53 Hz / 57 ~ 63 Hz or 47 ~ 53 Hz / 57 ~ 63 Hz or 47 ~ 53 Hz / 46~54 Hz or 56~64 Hz / 46~54 Hz or 56~64 Hz
Waveform (Batt. Mode)Pure Sinewave
AC Mode≥ 89% @ full charged battery / ≥ 89% @ full charged battery / ≥ 89% @ full charged battery / ≥ 89% @ full charged battery / 94% / 94%
Battery Mode≥ 88% / ≥ 88% / ≥ 88% / ≥ 88% / 92% / 92%
Battery Type12 V / 9 Ah / 12 V / 7 Ah / 12 V / 9 Ah / 12 V / 9 Ah / 12 V / 7 Ah / 12 V / 9 Ah
Numbers2 / 3 / 4 / 6 / 16 / 16
Charging Current2A / 2A / 2A / 2A / 1.0A / 1.0A

Mechanical

Dimension, D x W x H (mm)410 x 438 x 88 / 410 x 438 x 88 / 510 x 438 x 88 / 630 x 438 x 88 / 610 x 438 x 88 [2U] / 610 x 438 x 88 [2U]
Net Weight (kg)11.6 / 14.1 / 15.5 / 19.5 / 17 / 20
Weight11.6 / 14.1 / 15.5 / 19.5 / 17 / 20

Environmental

Humidity20-90 % RH @ 0-40°C (non-condensing)
Noise LevelLess than 50dB @ 1 Meter / Less than 50dB @ 1 Meter / Less than 50dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 55dB @ 1 Meter

Certifications

  • cTUVus (comply to UL1778)
  • FCC
