Voltronic Power Galleon III Tower RT 1-3K

Voltronic Galleon III Tower RT 1-3K

Discover the Voltronic Power Galleon III Tower RT 1-3K UPS with USB, RS-232 ports, and optional SNMP slot for reliable power protection.

Voltage: 200-240 VAC
Voltage Range: 110-300 VAC
Power Factor: >= 0.99

AED 3,000incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Voltronic Galleon III Tower RT 1-3K features

N/A

Hot-swappable battery design

Advanced communication and monitoring options

Programmable management outlets

About the Voltronic Galleon III Tower RT 1-3K

The Voltronic Power Galleon III Tower RT 1-3K is a robust uninterruptible power supply designed to ensure continuous power delivery. Equipped with USB and RS-232 communication ports, and an optional SNMP intelligent slot, it offers versatile connectivity and advanced protection. Ideal for safeguarding critical systems in data centers, telecommunications, and network environments, ensuring uninterrupted operation and data integrity.

Specifications last updated 27 March 2026

Voltronic Galleon III Tower RT 1-3K full specifications

Electrical

AC input	N/A
USB communication port	Yes
RS-232 communication port	Yes
SNMP intelligent slot	Optional
Communication Ports	USB port / RS-232 port / Intelligent slot / Intelligent slot / Intelligent slot / Intelligent slot
External Battery Connection	Voltage ≥ 1.25 x battery voltage/set / Current ≥ 50A / Current ≥ 50A / Current ≥ 50A / Current ≥ 50A / Current ≥ 50A
Nominal Voltage	200/208/220/230/240 VAC
Input Voltage Range	110 – 300 VAC / 110 – 300 VAC / 160 – 300 VAC / 160 – 300 VAC / 160 – 300 VAC / 160 – 300 VAC
Frequency Range	40 Hz ~ 70 Hz
Power Factor	≥ 0.99 @ nominal voltage (100% load)
THD	≤ 5% @ nominal voltage (100% load)
Output Voltage	200/208/220/230/240 VAC
AC Voltage Regulation (Batt. Mode)	± 1%
Frequency Range (Synchronized Range)	47 ~ 53 Hz or 57 ~ 63 Hz
Frequency Range (Batt. Mode)	50 Hz ± 1 Hz / 60Hz ± 0.1 Hz / 60Hz ± 0.1 Hz / 60Hz ± 0.1 Hz / 60Hz ± 0.1 Hz / 60Hz ± 0.1 Hz
Current Crest Ratio	3:1
Harmonic Distortion	≤ 2 % THD (Linear Load) ; ≤ 5 % THD (Non-linear Load)
Transfer Time	0 ms
Waveform (Batt. Mode)	Pure Sinewave
ECO mode @ full charged battery	96% / 97% / 97% / 97% / 97% / 97%
AC Mode @ full charged battery	92% / 92% / 92% / 93% / 93% / 94%
Battery Mode	86% / 89% / 89% / 89% / 89% / 91%
Battery Type	12 V / 9 Ah / 12 V / 7 Ah / 12 V / 9 Ah / 12 V / 9 Ah / 12 V / 7 Ah / 12 V / 9 Ah
Numbers	2 / 3 / 3 / 4 / 6 / 6
Typical Recharge Time	4 hours recover to 90% capacity for internal battery
Charging Current (CC)	1.5A
Charging Voltage (FV)	27.4VDC ± 1% / 41.0VDC ± 1% / 41.0VDC ± 1% / 54.8VDC ± 1% / 82.2VDC ± 1% / 82.2VDC ± 1%
EMC/Safety	CE (EMC: EN62040-2 C2)

Mechanical

Dimension, D x W x H (mm)	282 x 145 x 220 / 397 x 145 x 220 / 397 x 145 x 220 / 397 x 145 x 220 / 421 x 190 x 318 / 421 x 190 x 318
Net Weight (kgs)	9.8 / 11.4 / 13.8 / 17 / 22.5 / 26.2
Weight	9.8 / 11.4 / 13.8 / 17 / 22.5 / 26.2

Environmental

Modem/Phone/Network surge protection	Yes
Ambient Temperature Range	0°C to 40°C
Altitude	1000m
Humidity	20-90 % RH @ 0- 50°C (non-condensing)
Noise Level	Less than 50dB(A) @ 1 Meter with Fan speed control

Certifications

Frequently Asked Questions

The Galleon III Tower RT 1-3K is designed to provide reliable power with high efficiency. It supports a wide range of input voltages and offers robust surge protection for modem, phone, and network connections.

The UPS is compatible with external batteries, requiring a voltage of at least 1.25 times the battery voltage per set. However, it does not directly support solar panel connections.

The physical dimensions and weight of the Galleon III Tower RT 1-3K are not specified in the provided information. Please refer to the product manual for detailed specifications.

Installation requires a stable environment with an altitude of up to 1000 meters and an ambient temperature range of 0°C to 40°C. Ensure proper ventilation and secure mounting.

Warranty details are not specified in the provided information. It is recommended to contact Voltronic Power or your supplier for specific warranty terms.

The Galleon III Tower RT 1-3K does not list specific certifications or standards in the provided information.

The UPS operates efficiently within an ambient temperature range of 0°C to 40°C and is suitable for altitudes up to 1000 meters.

Key features include USB and RS-232 communication ports, optional SNMP intelligent slot, and surge protection for modem, phone, and network connections, ensuring reliable and versatile power management.
