Voltronic Power Victor 1U 6K UPS

Voltronic Victor 1U 6K UPS

Discover the Victor 1U 6K UPS by Voltronic Power with 208-240VAC output and precise voltage regulation of ±1%.

  • Voltage: 208-240 VAC
  • Voltage Range: 110-300 VAC
  • Power Factor: >= 0.99
AED 7,200incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Victor 1U 6K UPS features

True double-conversion

Microprocessor control optimizes reliability

Input power factor correction

Output power factor 0.9

Wide input voltage (110V –

Wide input voltage (110V – 300V)

Converter mode available

ECO mode for energy saving

Generator compatible

Smart SNMP and USB communication

10C high discharging rate on

10C high discharging rate on Lithium-ion battery module, high efficiency with 1U compact size

Comprehensive display allows easy monitoring

Comprehensive display allows easy monitoring and access of UPS

About the Voltronic Victor 1U 6K UPS

The Victor 1U 6K UPS by Voltronic Power is engineered to deliver reliable power protection with a nominal voltage range of 208 to 240VAC. Its robust design ensures consistent performance, making it an ideal choice for critical applications. The Victor 1U 6K UPS is perfect for data centers, telecommunications, and industrial environments where stable power is crucial.

Specifications last updated 27 March 2026

Voltronic Victor 1U 6K UPS full specifications

Electrical

Nominal Voltage208/220/230/240VAC
Voltage Range110-300VAC ± 3% @ 50% load; 176-300VAC ± 3% @ 100% load
Frequency Range46-54Hz; 56-64Hz
Power Factor≥ 0.99 @ nominal voltage (100% load)
THDi≤ 4% @ 100% load
Output Voltage208/220/230/240VAC
Voltage Regulation± 1%
Frequency Range (Synchronized Range)46-54 Hz or 56-64 Hz
Frequency Range (Batt. Mode)50 Hz or 60Hz ± 0.1 Hz
Current Crest Ratio3:1max
Harmonic Distortion≤ 2 % THD (Linear Load) / ≤ 4% THD (Non-linear Load)
Transfer Time0 ms
Waveform (Batt. Mode)Pure Sinewave
OverloadAC Mode 100% ≤ load ≤ 105% Warning only; 105%< load ≤ 125%: 1min; >125%: 1 sec
AC Mode95% (max.)
Charging Current1A, 2A, 4A (default), 6A
Charging Voltage219 VDC ± 1%
Battery Connector2 Poles (50A max.)
LCDLoad level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators
CommunicationUSB, Communication Slot
Battery Mode93% (max.)
Emergency Power Off (EPO)YES

Mechanical

Dimension, D x W x H (mm)520 x 438 x 44
Net Weight (kgs)9.8

Environmental

Humidity0-95% RH @ 0-40°C (non-condensing)
Altitude0-2000 meters without derating; 2000-3000 meters derating 1% every 100meters; >3000 meters: not working
Noise LevelLess than 55dBA @ 1 Meter
