Voltronic ePower DC UPS

Discover the Voltronic Power ePower DC UPS with a voltage range of 90-264 VAC and 12VDC output, offering reliable surge protection.

Voltage Range: 90-264 VAC
Frequency: 50/60 Hz
Surge Protection: 1.5KV (opt. 6KV)

AED 600incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Voltronic ePower DC UPS features

Built-in Li-ion battery

Microprocessor controller guarantees high reliability

Auto start when plugged in

Manual power off switch

Multi-color indicator

Overload, short-circuit, over-charge and over-discharge

Overload, short-circuit, over-charge and over-discharge protection

About the Voltronic ePower DC UPS

The Voltronic Power ePower DC UPS is engineered to deliver consistent power with a wide voltage range of 90 to 264 VAC. Designed for efficiency, it provides a stable 12VDC output, making it ideal for various applications. The ePower DC UPS is perfect for telecommunications, networking equipment, and other critical systems requiring uninterrupted power supply.

Specifications last updated 27 March 2026

Voltronic ePower DC UPS full specifications

Electrical

Voltage Range	90 VAC ~ 264 VAC
Frequency	50 or 60 Hz
Surge protection	1.5KV (Optional K.21 enhanced, 6KV)
Voltage	12VDC ± 5%
Max. Power	25W (2.1A)
Battery type	Lithium-ion Battery
Capacity	2600mAh
Typical Charging Time	3 hours recover to 90% capacity
Full Battery	Green lighting
Battery Mode	Constant flashing on Green LED
Battery Discharging	Quick flashing on Green LED
Fault	Red lighting
Battery	Deep Discharge, Over-charge and Short Circuit Protection
Battery Charging	Constant flashing on Green LED

Mechanical

Input Plug	Mounted on the housing (NEMA/EU/UK)
Output Cable	1m Length (DC Male Jack, OD 4mm, ID 1.7mm)
Dimension, D x W x H (mm)	68 x 42 x 74
Net Weight (g)	280

Environmental

Input/Output	Fuse for Short Circuit and Overload Protection

Frequently Asked Questions

The ePower DC UPS operates within a voltage range of 90 VAC to 264 VAC and supports frequencies of 50 or 60 Hz. It provides a maximum power output of 25W with a voltage of 12VDC ± 5%.

The ePower DC UPS is designed to work with a built-in lithium-ion battery with a capacity of 2600mAh. It does not directly support solar panels but can be integrated into systems that use them.

The ePower DC UPS is compact and lightweight, making it easy to install in various environments. However, specific dimensions and weight details are not provided in the key specifications.

Installation of the ePower DC UPS requires a stable connection to a power source within the specified voltage range. It should be installed in a location that allows for adequate ventilation.

Voltronic Power typically offers a standard warranty for its products, but specific warranty details for the ePower DC UPS should be confirmed with the retailer or distributor.

The ePower DC UPS complies with standard certifications, ensuring it meets industry safety and performance standards. Specific certifications are not detailed in the provided specifications.

The ePower DC UPS is designed to operate efficiently in a range of environmental conditions, but specific temperature and humidity ranges are not detailed in the key specifications.

Key features of the ePower DC UPS include surge protection up to 1.5KV, deep discharge, over-charge, and short circuit protection, as well as a quick charging time of 3 hours to recover 90% capacity.
