Voltronic Power Arena 2U/3U

Voltronic Arena 2U/3U

Discover the Voltronic Power Arena 2U/3U UPS with 3-phase voltage range 190-520 VAC and precise AC voltage regulation for reliable power.

  • Voltage: 100-415 VAC
  • Voltage Range: 88-520 VAC
  • Frequency: 40-70 Hz
AED 25,000incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Arena 2U/3U features

True double-conversion

DSP technology guarantees high reliability

Output power factor 1.0

50Hz/60Hz frequency converter mode

ECO mode operation for energy

ECO mode operation for energy saving

Emergency power off function (EPO)

Generator compatible

Customized system (only available for

Customized system (only available for Arena 3U)

Parallel operation with common battery

Adjustable battery design

About the Voltronic Arena 2U/3U

The Voltronic Power Arena 2U/3U UPS is engineered to deliver exceptional power protection with its robust 3-phase voltage capabilities. Designed to handle a wide voltage range and frequency, it ensures stable and reliable power supply for critical applications. Ideal for data centers, industrial facilities, and telecommunications, the Arena 2U/3U UPS provides seamless power continuity and protection against voltage fluctuations.

Specifications last updated 27 March 2026

Voltronic Arena 2U/3U full specifications

Electrical

Nominal Voltage3 x 360VAC/380VAC/400VAC/415VAC (3Ph+N+PE) / 3 x 360VAC/380VAC/400VAC/415VAC (3Ph+N+PE) / 208VAC/220VAC/230VAC/240VAC (1Ph+N+PE) / 100/200, 110/220, 120/208, 120/240, 127/220 VAC (2Ph+N+PE) / 3 x 360VAC/380VAC/400VAC/415VAC (3Ph+N+PE) / 3 x 360VAC/380VAC/400VAC/415VAC (3Ph+N+PE) / 208VAC/220VAC/230VAC/240VAC (1Ph+N+PE) / 100/200, 110/220, 120/208, 120/240, 127/220 VAC (2Ph+N+PE) / 3 x 173VAC/190VAC/200VAC/208VAC/220VAC (3Ph+N+PE)
Voltage Range190-520 VAC (3-phase) @ 50% load, 305-478 VAC (3-phase) @ 100% load / 190-520 VAC (3-phase) @ 50% load, 305-478 VAC (3-phase) @ 100% load / 110-300 VAC @ 50% load, 176-276 VAC @ 100% load / 88-155 VAC (L-N), 152-269 VAC (L-L) / 190-520 VAC (3-phase) @ 50% load, 305-478 VAC (3-phase) @ 100% load / 190-520 VAC (3-phase) @ 50% load, 305-478 VAC (3-phase) @ 100% load / 110-300 VAC @ 50% load, 176-276 VAC @ 100% load / 88-155 VAC (L-N), 152-269 VAC (L-L) / 88-155 VAC (L-N), 152-269 VAC (L-L)
Frequency Range40 Hz ~ 70 Hz
Power Factor>= 0.99 @ 100% load
THDi< 4% @ full linear load
Output Voltage360VAC/380VAC/400VAC/415VAC (3Ph+N) / 208*220/230/240VAC(L+N) / 208*220/230/240VAC(L+N) / 100/200,110/220,120/208,120/240,127/220VAC(2Ph+N) / 360VAC/380VAC/400VAC/415VAC (3Ph+N) / 208*220/230/240VAC(L+N) / 208*220/230/240VAC(L+N) / 100/200,110/220,120/208,120/240,127/220VAC(2Ph+N) / 173VAC/190VAC/200VAC/208VAC/220VAC(3Ph+N)
AC Voltage Regulation (Batt. Mode)± 1%
Frequency Range (Synchronized Range)46~54Hz or 56~64Hz
Frequency Range (Batt. Mode)50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
Current Crest Ratio3:1 (max.)
Harmonic Distortion≤ 2% THD (Linear Load) ; ≤ 3% THD (Non-linear Load)
Transfer Time0 ms
Waveform (Batt. Mode)Pure Sinewave
AC Mode94% / 94% / 93.5% / 91% / 94% / 94% / 93.5% / 91% / 92%
ECO Mode97% / 97% / 97% / 97% / 97% / 97% / 97% / 97% / 97%
Battery Mode At Full Load93% / 92.5% / 92% / 91% / 93% / 92.5% / 92% / 91% / 92%
Battery Mode Peak93.5% / 93% / 92.5% / 91.5% / 93.5% / 93% / 92.5% / 91.5% / 92%
Battery Voltage± 12V / 9 Ah
Battery Numbers12 pcs x 2 / 12 pcs x 2 / 12 pcs x 2 / 6 pcs x 2 / 16~20 pcs (adjustable) x 2 / 16~20 pcs (adjustable) x 2 / 16~20 pcs (adjustable) x 2 / 8~10pcs (adjustable) x 2 / 8~10pcs (adjustable) x 2
Charging Voltage± 164V / ± 164V / ± 164V / ± 82V / ± 218V / ± 218V / ± 218V / ± 109V / ± 109V
Typical Recharging Time9 hours recover to 90% capacity
Charging Current± 4A
LCD/LED DisplayUPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions
Smart RS-232/USBSupports Windows® Family, Linux and MAC
Optional SNMPPower management from SNMP manager and web browser

Mechanical

Dimension, D x W x H(mm)678 x 418 x 88 [2U] / 678 x 418 x 88 [2U] / 678 x 418 x 88 [2U] / 678 x 418 x 88 [2U] / 678 x 418 x 129 [3U] / 678 x 418 x 129 [3U] / 678 x 418 x 129 [3U] / 678 x 418 x 129 [3U] / 678 x 418 x 129 [3U]
Net Weight (kgs)17 / 17 / 17 / 14 / 20.5 / 20.5 / 20.5 / 17.6 / 21
Weight17 / 17 / 17 / 14 / 20.5 / 20.5 / 20.5 / 17.6 / 21

Environmental

Operating Humidity0-95 % RH @ 0- 40°C (non-condensing)
Noise LevelLess than 55dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 58dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 58dB @ 1 Meter / Less than 58dB @ 1 Meter
