Voltronic Power

Amber Line Interactive UPS

Discover the Voltronic Power Amber Line Interactive UPS with voltage options of 110/120 or 220/230/240 VAC and precise regulation.

Voltage: 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC
Voltage Range: 81-134VAC / 89-145VAC or 162-268VAC / 170-280VAC / 177-290VAC / 81-134VAC / 89-145VAC or 162-268VAC / 170-280VAC / 177-290VAC / 81-134VAC / 89-145VAC or 162-268VAC / 170-280VAC / 177-290VAC / 81-134VAC / 89-145VAC or 162-268VAC / 170-280VAC / 177-290VAC
Frequency Range: 50/60 Hz ± 5Hz

100 AEDincl. VAT

Features

Compact size for stand and

Compact size for stand and mounting flexibility

Excellent microprocessor control guarantees high

Excellent microprocessor control guarantees high reliability

Provides battery backup and surge

Provides battery backup and surge protected outputs

Boost and buck AVR for

Boost and buck AVR for voltage stabilization

Simulated sine wave output

Off-mode charging

Cold start function

Easy replacement battery compartment

Optional USB communication port and

Optional USB communication port and RJ-45 network protection

Optional USB charger port (5V/2.1A)

Optional USB charger port (5V/2.1A) for mobile devices

Overview

The Voltronic Power Amber Line Interactive UPS is engineered to provide reliable power protection with versatile voltage options of 110/120 VAC or 220/230/240 VAC. Its advanced design ensures stable performance with an AC voltage regulation of ±10% in battery mode. Ideal for safeguarding home and office electronics, the Amber Line Interactive UPS is perfect for computers, networking devices, and sensitive equipment.

Frequently Asked Questions

The Amber Line Interactive UPS operates with a voltage of 110/120 VAC or 220/230/240 VAC and a frequency range of 50/60 Hz ± 5Hz. It provides a simulated sine wave output in battery mode with an AC voltage regulation of ±10%.

The UPS uses a 12 V/4.5 Ah battery and is designed for standard grid applications. It does not support direct connection to solar panels without additional equipment.

The UPS has dimensions of 345 x 200 x 100 mm and weighs 4 kg. It does not have an IP rating, so it should be used in environments free from excessive dust and moisture.

The UPS should be installed in a well-ventilated area with a temperature range of 0-40°C and humidity levels between 0-90% RH (non-condensing). Ensure it is placed on a stable surface.

Voltronic Power typically offers a standard warranty for its UPS products. Please check with your retailer or the product documentation for specific warranty terms.

The Amber Line Interactive UPS complies with standard certifications, ensuring reliable performance and safety. Specific certifications can be confirmed with the manufacturer.

The UPS operates effectively in temperatures ranging from 0 to 40°C and humidity levels of 0-90% RH, provided the environment is non-condensing.

Key features include overload, discharge, and overcharge protection, a quick transfer time of 6ms typical, and a low noise level of less than 40dB, making it ideal for home and office use.

Amber Line Interactive UPS

Features

Compact size for stand and

Excellent microprocessor control guarantees high

Provides battery backup and surge

Boost and buck AVR for

Simulated sine wave output

Off-mode charging

Cold start function

Easy replacement battery compartment

Optional USB communication port and

Optional USB charger port (5V/2.1A)

Overview

Frequently Asked Questions
