Voltronic Power Apex Line Interactive UPS

Voltronic Apex Line Interactive UPS

Discover the Voltronic Power Apex Line Interactive UPS with voltage options of 110/120 or 220/230/240 VAC and auto-sensing frequency.

  • Voltage: 110-240 VAC
  • Voltage Range: 81-290 VAC
  • Frequency Range: 50/60 Hz (Auto sensing)
AED 1,400incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Apex Line Interactive UPS features

400VA, 600VA, 800VA, 1KVA, 1.5KVA,

400VA, 600VA, 800VA, 1KVA, 1.5KVA, 2KVA, 3KVA line interactive UPS

Touch screen LCD to display

Touch screen LCD to display UPS information circularly (option)

Compact size

Boost and buck AVR for

Boost and buck AVR for voltage stabilization

Auto restart while AC is

Auto restart while AC is recovering

Off-mode charging

Cold start function

Generator compatible (option)

No load shutdown in battery

No load shutdown in battery mode for 800VA and below models

Optional HID Power Device USB

Optional HID Power Device USB port

About the Voltronic Apex Line Interactive UPS

The Voltronic Power Apex Line Interactive UPS is engineered to deliver reliable power protection with versatile voltage options of 110/120 or 220/230/240 VAC. Its auto-sensing frequency range ensures seamless operation, making it an ideal choice for safeguarding your critical devices. The Apex Line Interactive UPS is perfect for home offices, small businesses, and IT environments, providing consistent power backup and voltage regulation.

Specifications last updated 27 March 2026

Voltronic Apex Line Interactive UPS full specifications

Electrical

Voltage110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 220/230/240 VAC
Voltage Range81-145 VAC / 162-290 VAC / 81-145 VAC / 162-290 VAC / 81-145 VAC / 162-290 VAC / 81-145 VAC / 162-290 VAC / 81-145 VAC / 162-290 VAC / 81-145 VAC / 162-290 VAC / 162-290 VAC
Frequency Range60/50 Hz (Auto sensing)
Output Voltage110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 220/230/240 VAC
AC Voltage Regulation (Batt. Mode)± 10%
Frequency Range (Batt. Mode)50 Hz or 60 Hz ± 1 Hz
Transfer TimeTypical 2-6 ms
Waveform (Batt. Mode)Simulated Sinewave
Battery Type & Number12 V/4.5 Ah x 1 / 12 V/7 Ah x 1 / 12 V/9 Ah x 1 / 12 V/7 Ah x 2 / 12 V/9 Ah x 2 / 12 V/9 Ah x 2 / 12 V/10 Ah x 2
Typical Recharge Time4-6 hours recover to 90% capacity
LCD ModelInput voltage, output voltage, battery capacity, load level and UPS status
LED ModeAC Mode: Green lighting / Battery Mode: Green flashing / Fault: N/A / Fault: N/A / Fault: N/A / Fault: N/A / Fault: N/A
Battery ModeSounding every 10 seconds
Low BatterySounding every second
OverloadSounding every 0.5 second
FaultContinuously sounding

Mechanical

LCD Dimension, D×W×H (mm)300 x 101 x 142 / 320 x 130 x 182 / 390 x 147 x 205 / 390 x 147 x 205 / 390 x 147 x 205 / 390 x 147 x 205 / 390 x 147 x 205
Net Weight (kgs)3.7 / 4.4 / 5.0 / 7.8 / 10.4 / 10.6 / 15.1
Weight3.7 / 4.4 / 5.0 / 7.8 / 10.4 / 10.6 / 15.1
LED Dimension, D×W×H (mm)279 x 101 x 142 / 320 x 130 x 182 / 390 x 147 x 205 / 390 x 147 x 205 / 390 x 147 x 205 / 390 x 147 x 205 / 390 x 147 x 205

Environmental

Full ProtectionOverload, discharge, and overcharge protection
Humidity0-90 % RH @ 0- 40°C (Non-condensing)
Noise LevelLess than 40dB / Less than 45dB / Less than 45dB / Less than 45dB / Less than 45dB / Less than 45dB / Less than 45dB
