Voltronic Power Prime Line Interactive UPS

Voltronic Prime Line Interactive UPS

Discover Voltronic Power's Prime Line Interactive UPS with precise voltage regulation and versatile output options for reliable power.

  • Voltage: 110-240 VAC
  • Frequency: 50/60 Hz
  • Transfer Time: 6ms typ, 10ms max
AED 1,300incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Prime Line Interactive UPS features

Simulated sine wave output

Boost AVR for voltage stabilization

Comprehensive LCD for real-time UPS

Comprehensive LCD for real-time UPS status

Provides battery backup and surge

Provides battery backup and surge protected outputs

Easy replacement battery compartment

Optional hot-swappable battery design

ENERGY STAR qualified for 120VAC

ENERGY STAR qualified for 120VAC models

Built-in USB com. port and

Built-in USB com. port and RJ-45 network protect

Optional coax surge protection for

Optional coax surge protection for TV antenna

Optional 5V USB charger port

Optional 5V USB charger port for mobile devices

Optional HID Power Device USB

Optional HID Power Device USB port

About the Voltronic Prime Line Interactive UPS

The Prime Line Interactive UPS by Voltronic Power offers exceptional performance with its precise voltage regulation and flexible output voltage options. Designed to maintain a stable power supply, it is ideal for safeguarding sensitive electronics against power fluctuations. The Prime Line Interactive UPS is perfect for home offices, small businesses, and critical IT environments, ensuring continuous power and protection for computers, servers, and networking equipment.

Specifications last updated 27 March 2026

Voltronic Prime Line Interactive UPS full specifications

Electrical

Output Voltage110/120 VAC or 220/230/240 VAC
AC Voltage Regulation (Batt. Mode)± 5%
Frequency Range (Batt. Mode)50 Hz / 60 Hz ± 1Hz
Transfer Time6ms typical, 10ms max
Waveform (Batt. Mode)Simulated Sinewave
Voltage110/120 VAC or 220/230/240VAC
Voltage Range81-132VAC / 86-142VAC or 162-270VAC / 170-270VAC / 176-270VAC
Frequency Range50 Hz / 60 Hz ± 5Hz (Auto Sensing)
Battery Type & Number12 V/7 Ah x 1 / 12 V/9 Ah x 1 / 12 V/9 Ah x 1 / 12 V/9 Ah x 1 / 12 V/9 Ah x 2 / 12 V/9 Ah x 2 / 12 V/9 Ah x 2
Typical Recharge Time6-8 hours recover to 90% capacity
Optional USB PortSupports Windows® Family, Linux and MAC
Compliance & Standards110/120VAC model: cTUVus (standard:UL 1778), FCC Part 15 Class B, ENERGY STAR (USA) / 220/230/240VAC model: LVD: EN 62040-1, EMC:EN 62040-2 (Class B) / 220/230/240VAC model: LVD: EN 62040-1, EMC:EN 62040-2 (Class B) / 220/230/240VAC model: LVD: EN 62040-1, EMC:EN 62040-2 (Class B) / 220/230/240VAC model: LVD: EN 62040-1, EMC:EN 62040-2 (Class B) / 220/230/240VAC model: LVD: EN 62040-1, EMC:EN 62040-2 (Class B) / 220/230/240VAC model: LVD: EN 62040-1, EMC:EN 62040-2 (Class B)

Mechanical

Dimension, D x W x H (mm)288 x 99 x 280 / 288 x 99 x 280 / 288 x 99 x 280 / 288 x 99 x 280 / 410 x 99 x 280 / 410 x 99 x 280 / 410 x 99 x 280
Net Weight (kgs)6.1 / 7.1 / 7.8 / 8.5 / 11.1 / 11.6 / 12
Weight6.1 / 7.1 / 7.8 / 8.5 / 11.1 / 11.6 / 12

Environmental

Full ProtectionOverload, discharge, output short circuit and overcharge protection
Humidity0-90 % RH @ 0- 40°C (Non-condensing)
Noise LevelLess than 40dB / Less than 40dB / Less than 40dB / Less than 40dB / Less than 45dB / Less than 45dB / Less than 45dB

Certifications

  • CE
  • FCC
  • TUV
  • ENERGY STAR
