Voltronic Nano

Discover Voltronic Power's Nano UPS with 110/120VAC or 220/230/240VAC output, ensuring reliable power with ±10% voltage regulation.

Output Voltage: 110-240 VAC
Regulation (Batt.): ± 10%
Transfer Time: 2-6 ms

AED 350incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Voltronic Nano features

400VA, 600VA, 800VA standby UPS

Compact size with stand and

Compact size with stand and wall mounting flexibility

Auto restart while AC is

Auto restart while AC is recovering

Simulated sine wave output

Cold start function

Full protection: discharge, overcharge, short

Full protection: discharge, overcharge, short circuit, and thermal protection

About the Voltronic Nano

The Voltronic Power Nano UPS is designed to provide seamless power backup with an output voltage of 110/120 VAC or 220/230/240 VAC. With precise voltage regulation and quick recharge capabilities, it ensures your devices remain powered during outages. Ideal for home and office use, the Nano UPS is perfect for safeguarding computers, networking devices, and other sensitive electronics from power interruptions.

Specifications last updated 27 March 2026

Voltronic Nano full specifications

Electrical

Output Voltage	110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 110/120 VAC or 220/230/240 VAC / 220/230/240 VAC / 220/230/240 VAC
Voltage Regulation (Batt. Mode)	± 10% / ± 10% / ± 10% / ± 10% / ± 10% / ± 10% / ± 10% / ± 10%
Frequency Range (Batt. Mode)	50Hz or 60Hz ± 1 Hz / 50Hz or 60Hz ± 1 Hz / 50Hz or 60Hz ± 1 Hz / 50Hz or 60Hz ± 1 Hz / 50Hz or 60Hz ± 1 Hz / 50Hz or 60Hz ± 1 Hz / 50Hz ± 1 Hz / 50Hz ± 1 Hz
Transfer Time (Typical)	2-6 ms
Waveform (Batt. Mode)	Simulated Sinewave
Battery Type and Quantity	12 V / 4.5 Ah x 1 / 12 V / 7 Ah x 1 / 12 V / 9 Ah x 1 / 12 V / 4.5 Ah x 1 / 12 V / 7 Ah x 1 / 12 V / 9 Ah x 1 / 12 V / 4.5 Ah x 1 / 12 V / 5 Ah x 1
Typical Recharge Time	8 hours recover to 90% capacity
Smart USB (Option)	N/A / Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8/10, Linux and MAC / N/A / N/A / N/A / N/A / N/A / N/A

Mechanical

Dimension (D x W x H) (mm)	228 x 82.5 x 207 (Vertically stand) / 228 x 82.5 x 207 (Vertically stand) / 228 x 82.5 x 207 (Vertically stand) / 228 x 82.5 x 207 (Vertically stand) / 228 x 82.5 x 207 (Vertically stand) / 228 x 82.5 x 207 (Vertically stand) / 166 x 161 x 89.2 / 166 x 161 x 89.2
Net Weight (kgs)	2.2 / 2.7 / 3.1 / 2.2 / 2.7 / 3.1 / 2.25 / 2.56
Weight	2.2 / 2.7 / 3.1 / 2.2 / 2.7 / 3.1 / 2.25 / 2.56

Environmental

Humidity	0-90 %
Operating Temperature	0-40°C (non-condensing)

Frequently Asked Questions

The Voltronic Power Nano UPS offers an output voltage of 110/120 VAC or 220/230/240 VAC with a voltage regulation of ± 10% in battery mode. It operates at a frequency range of 50Hz or 60Hz ± 1 Hz, and features a transfer time of 2-6 ms with a simulated sinewave output.

The Nano UPS uses a 12 V / 4.5 Ah battery. It is not specifically designed for solar panel integration, and its compatibility with other battery types is not indicated.

The Nano UPS has dimensions of 228 x 82.5 x 207 mm and weighs 2.2 kg. It is designed to stand vertically, but does not have an IP rating for dust or water resistance.

The Nano UPS should be installed in a non-condensing environment with an operating temperature between 0-40°C and humidity levels from 0-90%.

The warranty information for the Voltronic Power Nano UPS is not specified in the provided details. It is recommended to check with the retailer or manufacturer for warranty specifics.

The Nano UPS meets standard certifications, ensuring compliance with industry norms for safety and performance.

The Nano UPS operates effectively within a temperature range of 0-40°C and can handle humidity levels from 0-90%, provided the environment is non-condensing.

Key features of the Nano UPS include its compact size, quick transfer time of 2-6 ms, and simulated sinewave output, making it suitable for protecting sensitive electronic devices from power interruptions.
