Voltronic Power LIO 4805

Voltronic LIO 4805

Discover the Voltronic Power LIO 4805 Energy Storage System with 2400Wh capacity and 48VDC nominal voltage for efficient energy management.

  • Capacity: 2400Wh
  • Nominal Voltage: 48VDC
  • Full Charge Voltage (FC): 52.5VDC
  • Full Discharge Voltage (FD): 34.5VDC
AED 6,500incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic LIO 4805 features

Modular design, up to 10

Modular design, up to 10 in parallel for capacity extension

Built-in BMS, communication with power

Built-in BMS, communication with power module via RS-485

Life cycle: 8000 cycles at

Life cycle: 8000 cycles at 25°C, 60% DoD

Big discharging current design 75A(50Ah)/150A(100Ah)

Finger proof design for external

Finger proof design for external battery connector

Flexible front and Rear installation

Built-in breaker for safety operation

Easy capacity extension by paralleled

Aluminum case LiFeO4 for cells,

Aluminum case LiFeO4 for cells, more safety and stable

Customer-made protocol upgrade support

About the Voltronic LIO 4805

The Voltronic Power LIO Series Energy Storage System is designed to deliver reliable and efficient energy storage solutions. With a capacity of 2400Wh and a nominal voltage of 48VDC, this system is perfect for various energy management applications. Ideal for residential and commercial energy storage, the LIO Series supports backup power, renewable energy integration, and peak shaving.

Specifications last updated 23 July 2026

Voltronic LIO 4805 full specifications

Electrical

Capacity2400Wh
Nominal Voltage48VDC
Full Charge Voltage (FC)52.5VDC
Full Discharge Voltage (FD)34.5VDC
Typical Capacity50Ah
Max Continuous Discharging Current75A
Max Peak Discharging Current100A
Battery Connector Max Current75A
ProtectionBMS, Breaker
Charge Voltage52.5 ± 0.1V
Maximum Charge Current50A (0.5C)
Standard Charge Method0.2C CC (Constant current) charge to FC, CV (Constant voltage FC) charge till charge current decline to <0.05C
Inner Resistance<20m ohm
LEDBattery Status, Battery level, Battery fault, Alarm
CommunicationRS485 port (RJ45), extension port (RJ11)
CertificationsUN38.3, IEC 62619
Design Life>10 years @ 25°C
Lifecycle> 4500 @ 25°C

Mechanical

Dimension, D x W x H (mm)676 x 438 x 86
Net Weight (kgs)31.6

Environmental

Operating Environment - Charge0°C~50°C
Operating Environment - Discharge0°C~50°C
Storage Temperature< 18 months: -20°C~25°C
Recommended Storage Temperature20°C ± 5°C

Certifications

  • UN38.3
  • IEC 62619
