LIO II-4810
- Battery Cell Technology:Lithium Iron Phosphate
- Applicable Inverter Rating:5.6-12 kW
AED 7,800
Buy Now — LIO II-4810
Voltronic LIO II-4810 Lithium Battery
The LIO II 4810 Lithium Battery Pack LIOII-4810 is a lithium battery rated LIOII-4810.
- Protection: BMS
- Standard Charge Method: 0.2C CC (Constant Current) charge to FC, CV (Constant Voltage) charge till charge current decline to <0.05C
- Inner Resistance: <20ΜΩ
AED 1incl. VAT
In stock
About the Voltronic LIO II-4810 Lithium Battery
The LIO II 4810 Lithium Battery Pack LIOII-4810 is a lithium battery rated LIOII-4810. Every figure on this page is read from the manufacturer's manual for the LIO II 4810 Lithium Battery Pack series.
Specifications last updated 17 August 2026
Voltronic LIO II-4810 Lithium Battery full specifications
Electrical
| Protection | BMS |
|---|---|
| Standard Charge Method | 0.2C CC (Constant Current) charge to FC, CV (Constant Voltage) charge till charge current decline to <0.05C |
| Inner Resistance | <20ΜΩ |
| Communication | RS485 (RJ45), extension port (RJ11) |
| Certifications | UN38.3, IEC 62619, EN 61000-6-3 EN 61000-6-1, UKCA |
| Capacity (Wh) | 5120 Wh |
| Nominal Voltage | 51.2 VDC |
| Typical Capacity(Ah) | 100 Ah |
| Full Charge Voltage (FC) | 56 V ± 0.1 V |
| Full Discharge Voltage (FD) | 42 V |
| Max. Continuous Discharge Current | 150 A |
| Max. Peak Discharge Current | 192 A at 1min |
| Max. Charge Voltage | 56 V ± 0.1 V |
| Max. Charge Current | 100 A (Default 30A) |
Mechanical
| Dimension (D x W x H) mm | 185 x 540 x 420 |
|---|---|
| Dimension with stand feet | 185 x 540 x 530 |
| Net Weight (kg) | 48 |
Environmental
| Operation Temperature | Charge: 0°C~50°C Discharge: 0°C~50°C |
|---|---|
| Storage Temperature | -20ºC ~ 60 °C 20°C±5°C is the recommended storage temperature |
