Voltronic Power LIO II-4810E

Voltronic LIO II-4810E

Discover the Voltronic Power LIO II-4810E with Lithium Iron Phosphate technology, 51.

  • Battery Cell Technology: Lithium Iron Phosphate
  • Nominal Voltage: 51.2 V
  • Battery Capacity: 100Ah
  • Max. Continuous Charging / Discharging Current: 50A/100A @ 25°C
AED 8,200incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic LIO II-4810E features

Built-in Active Cell Balancing, ensuring

Built-in Active Cell Balancing, ensuring optimal performance and longevity of the battery pack

Wall-mounted scalable Lithium-ion battery module

Scalable design up to 15

Scalable design up to 15 units

About the Voltronic LIO II-4810E

Introducing the Voltronic Power LIO II-4810E, a cutting-edge energy storage system designed for efficiency and reliability. With advanced Lithium Iron Phosphate technology, this system offers a nominal voltage of 51.2V and a robust capacity of 100Ah, ensuring optimal performance in various conditions. The LIO II-4810E is ideal for residential energy storage, commercial backup power, and renewable energy integration, providing a reliable and efficient power solution.

Specifications last updated 27 March 2026

Voltronic LIO II-4810E full specifications

Electrical

Inner Resistance<20ΜΩ
CertificationsUN38.3, IEC 62619, EN 61000-6-3 EN 61000-6-1, UKCA
Standard Charge Method0.2C CC (Constant Current) charge to FC, CV (Constant Voltage) charge till charge current decline to <0.05C
Battery Cell TechnologyLithium Iron Phosphate
Nominal Voltage51.2 V
Battery Capacity100Ah
Max. Continuous Charging / Discharging Current50A/100A @ 25°C
Max. Charging Voltage57.6 V
Max. Discharging Voltage43.2 V
Max. Parallel Unit15
Dimension, D X W X H (mm)140 x 450 x 500
Net Weight (kg)43
BMS CommunicationRS485, RS232, CAN
Safety StandardEN IEC 61000-6-3, EN IEC 61000-6-1, EN IEC 61000-3-2, IEC 61000-3-3, IEC 62619, UN38.3

Environmental

Operation TemperatureCharge: 0°C~50°C Discharge: 0°C~50°C
Operation Temperature (Charge)0°C~45°C
Operation Temperature (Discharge)-20°C~60°C (>45°C derating)
Operation Humidity5% ~ 95% RH (non-condensing)
Operation Air Pressure61 kPa~ 113 kPa
Lifecycle4000 cycles @ 80% DOD
IP ProtectionIP65

Certifications

  • CE
  • UN38.3
