Voltronic Power LIO II-4810

Voltronic LIO II-4810

Discover the Voltronic Power LIO II-4810 with 5 kWh usable energy and lithium iron phosphate technology for efficient energy storage.

  • Battery Cell Technology: Lithium Iron Phosphate
  • Applicable Inverter Rating: 5.6-12 kW
  • Usable Energy: 5-20 kWh
  • Rated Discharging Current: 150 A
AED 7,800incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic LIO II-4810 features

Lithium Iron Phosphate (LFP) cell

Lithium Iron Phosphate (LFP) cell guarantees safety and reliability

Compact size and lightweight

Modular design for easy scalability

Fast charging capability

Maximum lifecycle of 8000 cycles

Maximum lifecycle of 8000 cycles at 60% DOD

About the Voltronic LIO II-4810

The Voltronic Power LIO II-4810 is a cutting-edge energy storage system designed for optimal performance. With a 5 kWh usable energy capacity and advanced lithium iron phosphate battery technology, it ensures reliability and efficiency for various applications. Ideal for residential and small commercial setups, the LIO II-4810 supports inverters up to 5.6 kW, making it perfect for backup power and renewable energy integration.

Specifications last updated 27 March 2026

Voltronic LIO II-4810 full specifications

Electrical

Inner Resistance<20ΜΩ
CertificationsUN38.3, IEC 62619, EN 61000-6-3 EN 61000-6-1, UKCA
Standard Charge Method0.2C CC (Constant Current) charge to FC, CV (Constant Voltage) charge till charge current decline to <0.05C
Battery Cell TechnologyLithium Iron Phosphate
Applicable Inverter Rating≤ 5.6 kW / 6 kW – 12 kW / 6 kW – 12 kW / 6 kW – 12 kW
Usable Energy5 kWh / 10 kWh / 15 kWh / 20 kWh
Rated Discharging Current150 A / 150 A / 150 A / 150 A
Peak Discharging Current192 A, 1 min / 192 A, 1 min / 192 A, 1 min / 192 A, 1 min
Nominal Voltage51.2 V
Operating Voltage40 – 56 VDC
Charging Current100 A Max, 30 A Default
Dimension, D x W x H (mm) without feet185 x 540 x 420 / 185 x 540 x 840 / 185 x 540 x 1260 / 185 x 540 x 1680
Net Weight (kg)48 / 96 / 144 / 192
Weight48 / 96 / 144 / 192
Operation Temperature (Charge)0°C–50°C
Storage Temperature< 18 months: -20°C–25°C / < 3 months: 25°C–45°C / < 1 month: 45°C–60°C / < 1 month: 45°C–60°C
IP ProtectionIP20
CommunicationRS485 port (RJ45), CAN
Full Charge Voltage (FC)56 V ± 0.1 V
Full Discharge Voltage (FD)42 V
ProtectionBMS

Environmental

Operation TemperatureCharge: 0°C~50°C Discharge: 0°C~50°C

Certifications

  • IEC 62619
  • EN 61000-6-3
  • EN 61000-6-1
  • UKCA
  • UN38.3
