Voltronic Power Winner Pro+

Voltronic Winner Pro+

Discover the Winner Pro+ Online UPS by Voltronic Power with a nominal voltage of 110-240VAC and precise voltage regulation of ±1%.

  • Nominal Voltage: 110-240 VAC
  • Input Voltage Range: 60-300 VAC
  • Power Factor: > 0.99
AED 8,500incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Winner Pro+ features

True double-conversion

Microprocessor control optimizes reliability

Input power factor correction

Output power factor 0.9

Wide input voltage range

Converter mode available

ECO mode for energy saving

Adjustable battery numbers

Generator compatible

Smart SNMP works well with

Smart SNMP works well with either USB or RS-232 together

Comprehensive display allows easy monitoring

Comprehensive display allows easy monitoring and access of UPS status

About the Voltronic Winner Pro+

The Winner Pro+ by Voltronic Power is a state-of-the-art Online UPS designed to deliver reliable power protection. With a nominal voltage range of 110-240VAC and a frequency range of 40-70 Hz, it ensures consistent performance and stability for your critical systems. Ideal for data centers, telecommunications, and critical IT infrastructure, the Winner Pro+ provides seamless power backup and voltage regulation to protect sensitive equipment.

Specifications last updated 27 March 2026

Voltronic Winner Pro+ full specifications

Electrical

Nominal Voltage110/115/120/127VAC or 208/220/230/240VAC / 110/115/120/127VAC or 208/220/230/240VAC / 110/115/120/127VAC or 208/220/230/240VAC / 208/220/230/240VAC / 208/220/230/240VAC
Input Voltage Range60-145 VAC or 120-300 VAC (Based on load at 50%) / 60-145 VAC or 120-300 VAC (Based on load at 50%) / 60-145 VAC or 120-300 VAC (Based on load at 50%) / 110-300 VAC (Based on load at 50%) / 176-300 VAC (Based on load at 100%)
Frequency Range40 Hz ~ 70 Hz / 40 Hz ~ 70 Hz / 40 Hz ~ 70 Hz / 46~54 Hz or 56~64 Hz / 46~54 Hz or 56~64 Hz
Power Factor> 0.99 @ Nominal Voltage (100% load)
Output Voltage110/115/120/127VAC or 208/220/230/240VAC / 110/115/120/127VAC or 208/220/230/240VAC / 110/115/120/127VAC or 208/220/230/240VAC / 208/220/230/240VAC / 208/220/230/240VAC
Voltage Regulation± 1%
Frequency Range (Synchronized Range)47 ~ 53 Hz or 57 ~ 63 Hz / 47 ~ 53 Hz or 57 ~ 63 Hz / 47 ~ 53 Hz or 57 ~ 63 Hz / 46~54 Hz or 56~64 Hz / 46~54 Hz or 56~64 Hz
Frequency Range (Batt. Mode)50 Hz or 60Hz ± 0.5% / 50 Hz or 60Hz ± 0.5% / 50 Hz or 60Hz ± 0.5% / 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz / 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
Current Crest Ratio3:1
Harmonic Distortion≤ 3 % THD (Linear Load) ≤ 6 % THD (Non-linear Load) / ≤ 3 % THD (Linear Load) ≤ 6 % THD (Non-linear Load) / ≤ 3 % THD (Linear Load) ≤ 6 % THD (Non-linear Load) / ≤ 3 % THD (Linear Load) ≤ 5 % THD (Non-linear Load) / ≤ 3 % THD (Linear Load) ≤ 5 % THD (Non-linear Load)
Transfer Time4 ms (Typical) / 4 ms (Typical) / 4 ms (Typical) / Zero / Zero
Waveform (Batt. Mode)Pure Sinewave
AC Mode88% / 89% / 90% / 92% / 93%
Battery Mode83% / 87% / 88% / 90% / 91%
Battery Type12 V / 9 Ah
Numbers2 / 3 / 4 / 6 / 8
Standard Model Typical Recharge Time4 hours recover to 90% capacity / 4 hours recover to 90% capacity / 4 hours recover to 90% capacity / 9 hours recover to 90% capacity / 9 hours recover to 90% capacity
Charging Current (max.)1 A / 1 A / 1 A / 1 A/2 A / 1 A/2 A
Charging Voltage27.4VDC ± 1% / 41.0VDC ± 1% / 54.7 VDC ± 1% / 82.1 VDC ± 1% 218.4 VDC ± 1% / 273VDC ± 1% 218.4 VDC ± 1% 273VDC ± 1%
Smart RS-232 / USBSupports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8/10, Linux and MAC
Optional SNMPPower management from SNMP manager and web browser

Mechanical

Dimension, D x W x H (mm)282 x 145 x 397 / 282 x 145 x 397 / 282 x 145 x 397 / 421 x 190 x 318 / 442 x 190 x 318
Net Weight (kgs)9.8 / 11.4 / 17 / 26.2 / 27.6
Weight9.8 / 11.4 / 17 / 26.2 / 27.6

Environmental

Humidity20-90 % RH @ 0-40°C (Non-condensing) / 20-90 % RH @ 0-40°C (Non-condensing) / 20-90 % RH @ 0-40°C (Non-condensing) / 0-95% RH @ 0-50°C (Non-condensing) / 0-95% RH @ 0-40°C (Non-condensing)
Noise LevelLess than 50dB @ 1 Meter / Less than 50dB @ 1 Meter / Less than 50dB @ 1 Meter / Less than 55dB @ 1 Meter / Less than 58dB @ 1 Meter
