True online double conversion with
True online double conversion with DSP control
Voltronic Giant II 3P/3P
Discover the Voltronic Power Giant II 3P/3P UPS with 6 pulse rectifier and 380VAC/400VAC/415VAC nominal voltage for reliable power solutions.
- Rectifier Type: 6/12 pulse
- Nominal Voltage: 380/400/415 VAC
- Voltage Range: 304-456 VAC
AED 110,000incl. VAT
In stock
Voltronic Giant II 3P/3P features
About the Voltronic Giant II 3P/3P
The Voltronic Power Giant II 3P/3P UPS is engineered to deliver robust and reliable power management solutions. With a 6 pulse rectifier and a nominal voltage range of 380VAC to 415VAC, it ensures optimal performance for critical applications. Ideal for data centers, industrial facilities, and telecommunications, the Giant II 3P/3P UPS provides consistent power protection and efficiency.
Specifications last updated 27 March 2026
Voltronic Giant II 3P/3P full specifications
Electrical
| Rectifier Type | 6 pulse / 6 pulse / 6 pulse / 6 pulse / 6 pulse / 6 pulse / 12 pulse / 12 pulse / 12 pulse / 12 pulse |
|---|---|
| Nominal Voltage | 380VAC/400VAC/415VAC |
| Acceptable Voltage Range | 304VAC – 456VAC |
| Frequency | 50Hz ± 10% |
| TVSS | 40kA (optional) |
| Input Voltage Range | 285VAC – 475VAC |
| Battery Voltage | 384 VDC (adjustable) |
| Cold Start | Yes |
| Power Factor | 0.9, customized up to 1.0 |
| Nominal Output Voltage | 380VAC/400VAC/415VAC |
| Output Voltage Regulation | ±1% |
| Overload Capability | 110% continuous running; 125% for 10 min; >150% for 1 min |
| Dry Contacts | 5 outputs and 4 inputs |
| Optional SNMP | Power management from SNMP manager and web browser |
| Safety | IEC62040-1:2017 |
| Modbus RS-232/RS-485 | Supports Windows® family, Linux and MAC |
Mechanical
| IP Protection | IP31 (default), IP42 (optional) |
|---|---|
| Dimensions (DxWxH) mm | 656 x 405 x 817 / 656 x 405 x 941 / 818 x 432 x 1159 / 971 x 554 x 1290 / 971 x 635 x 1326 / 1051 x 705 x 1646 / 1051 x 705 x 1646 / 1051 x 705 x 1646 / 1051 x 705 x 1646 / 1051 x 705 x 1646 |
| Net Weight (Kgs) | 120 / 145 / 193 / 278 / 365 / 471 / 573 / 650 / 735 / 790 |
| Weight | 120 / 145 / 193 / 278 / 365 / 471 / 573 / 650 / 735 / 790 |
Environmental
| Operating Temperature | 0 – 50°C |
|---|---|
| Storage Temperature | -25°C – 55°C |
| Humidity | 0–95% (non-condensing) |
| Altitude | 1000m |
Certifications
- IEC62040-1:2017
