Voltronic Power Giant iND II

Voltronic Giant iND II

Discover Voltronic Power's Giant iND II UPS with dual input support and flexible voltage range for reliable power management.

  • Rectifier: 6/12 pulse
  • Voltage: 380-415 VAC
  • Voltage Range: 304-456 VAC
AED 45,000incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Giant iND II features

Patented chassis structure offers 100%

Patented chassis structure offers 100% front access

Temperature compensation to prolong battery

Temperature compensation to prolong battery life

Backfeed protection and in-built 40kA

Backfeed protection and in-built 40kA surge protection

7” colored LCD with customized

7” colored LCD with customized control setting

Accepts dual-mains inputs

Parallel capability up to 4

Parallel capability up to 4 units

About the Voltronic Giant iND II

The Giant iND II by Voltronic Power is a versatile UPS solution designed to meet the demanding needs of modern power systems. With options for 6 pulse or 12 pulse rectifiers and dual input support, this UPS ensures seamless operation across various voltage settings. Ideal for data centers, telecommunications, and industrial applications, the Giant iND II provides robust power protection and management.

Specifications last updated 27 March 2026

Voltronic Giant iND II full specifications

Electrical

Rectifier Type6 pulse or 12 pulse
Main Input and Bypass InputSupports dual inputs
Nominal Voltage380VAC/400VAC/415VAC
Acceptable Voltage Range304VAC ~ 456VAC
Frequency50Hz/60Hz ± 10%
TVSS40kA
Input Voltage Range165VAC ~ 275VAC
Battery Voltage220VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable) / 384VDC (Adjustable)
Cold StartYes
Power Factor0.8 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0 / 0.9, customized up to 1.0
Nominal Output Voltage220VAC/230VAC/240VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC / 380VAC/400VAC/415VAC
Output Voltage Regulation±1%
Overload Capability110% continuous running; 125% for 10 min; >150% for 1 min
Dry Contacts5 outputs and 4 inputs
Optional SNMPPower management from SNMP manager and web browser
SafetyIEC62040-1-2017
EMC ImmunityIEC61000-4-5
EMC EmissionsIEC62040-2-2018
ApprovalsCE / CB/ Conformance testing / EMC / ROHS2 / Reach / YDT1095-2018
Modbus RS-232/RS485Supports Windows® family, Linux and MAC

Mechanical

IP ProtectionIP31 (default), IP42 (optional)
Dimensions, DxWxH (mm)800 x 800 x 1800 / 800 x 1200 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800 / 800 x 1600 x 1800
Net Weight (Kgs)354 / 400 / 480 / 680 / 910 / 1010 / 1360 / 1620 / 285 / 319 / 337 / 387 / 468 / 523 / 349 / 385 / 427
Weight354 / 400 / 480 / 680 / 910 / 1010 / 1360 / 1620 / 285 / 319 / 337 / 387 / 468 / 523 / 349 / 385 / 427

Environmental

Operating Temperature0~ 40°C
Storage Temperature-25°C ~ 55°C
Humidity0~95% (non-condensing)
Altitude1000m

Certifications

  • CE
  • CB
  • EMC
  • ROHS2
  • Reach
  • YDT1095-2018
