Voltronic Power Giant Elite 3P/1P

Voltronic Giant Elite 3P/1P

Discover the Giant Elite 3P/1P UPS by Voltronic Power with 3 x 360VAC/380VAC/400VAC nominal voltage and ±1% voltage regulation.

  • Nominal Voltage: 3x 360/380/400 VAC
  • Voltage Range: 286-493 VAC
  • Frequency: 40-64 Hz
AED 35,000incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Voltronic Giant Elite 3P/1P features

Galvanic isolation design to withstand

Galvanic isolation design to withstand all kinds of loads

Output power factor 0.8

Fully coating PCBs to withstand

Fully coating PCBs to withstand harsh environment

Unique ventilation design for effective

Unique ventilation design for effective heat dissipation

Wide input voltage and frequency

Wide input voltage and frequency range to withstand robust environment

High short-circuit and overload capabilities

Built-in maintenance bypass switch

About the Voltronic Giant Elite 3P/1P

The Giant Elite 3P/1P by Voltronic Power is a robust UPS solution designed for high-performance power management. With a nominal voltage range of 3 x 360VAC/380VAC/400VAC and precise voltage regulation of ±1%, it ensures reliable and efficient power delivery. Ideal for data centers, industrial applications, and critical systems, the Giant Elite 3P/1P provides stable power to safeguard sensitive equipment from disruptions.

Specifications last updated 27 March 2026

Voltronic Giant Elite 3P/1P full specifications

Electrical

Nominal Voltage3 x 360VAC/380VAC/400VAC (3Ph + N + G)
Voltage Range286VAC – 493VAC @ 16 pcs of batteries / 320VAC – 493VAC @ 18 pcs of batteries / 320VAC – 493VAC @ 18 pcs of batteries
Frequency40 Hz ~ 55 Hz @ 50Hz system ; 56 Hz ~ 64 Hz @ 60Hz system
Output Voltage208VAC/220VAC/230VAC (Selectable)
Voltage Regulation± 1%
Frequency Range (Synchronized Range)45Hz ~ 55 Hz or 56 Hz ~ 64 Hz
Frequency Range (Batt. Mode)50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz
Current Crest Ratio3:1
Harmonic Distortion≤ 3 % THD (Linear Load) ; ≤ 5 % THD (Non-linear Load)
Transfer Time0 ms
Waveform (Batt. Mode)Pure Sinewave
AC Mode83%
Battery Type12V / 9Ah
Battery Numbers*16 pcs / 16 pcs / 18 pcs
Recharging Time6 hours recover to 90% capacity
Charging Current (max.)2A
Charging Voltage218.4 V ± 1% / 245.7 V ± 1% / 218.4 V ± 1%
Smart RS-232/USBSupports Windows 2000/2003/XP/Vista/2008/7/8/10, Linux, Unix, and MAC
Optional SNMPPower management from SNMP manager and web browser
Battery Mode92%

Mechanical

Dimensions, DxWxH (mm)592 x 300 x 826
Net Weight (Kgs)129 / 137 / 152
Weight129 / 137 / 152

Environmental

Operating Temperature0 – 50°C (battery life cycle will be shorten when temperature is above 25°C)
Operating Humidity< 95 % and non-condensing
Noise LevelLess than 60dB@ 1 Meter
