Voltronic Power Automatic Transfer Switch ATS-30A

Voltronic Automatic Transfer Switch ATS-30A

Discover Voltronic Power's Automatic Transfer Switch ATS-30A with 220/230/240 VAC input and 10A/16A/30A output, ideal for seamless power transitions.

Input Voltage: 220/230/240 VAC
Acceptable Input Voltage: 180 - 258 VAC
Input Frequency: 60 Hz
Maximum Input Current: 30 A

AED 450incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Voltronic Automatic Transfer Switch ATS-30A features

Powered by two separately independent

Dual power supply for redundancy

Provides seamless power switch for

Provides seamless power switch for IT equipment

Preferred source selection on front

Preferred source selection on front panel

Highly reliability 19" rack design

Highly reliability 19" rack design (1U)

Built-in intelligent slot for SNMP

Built-in intelligent slot for SNMP or Modbus

Built-in USB and RS-232 communications

About the Voltronic Automatic Transfer Switch ATS-30A

The Voltronic Power Automatic Transfer Switch is a reliable UPS accessory designed to ensure seamless power transitions. With input voltages of 220/230/240 VAC and a maximum output current of 10 A for IEC-C13 outlets, 16 A for the IEC-C19 outlet and 30 A for the cable gland, this switch is perfect for maintaining uninterrupted power supply. Ideal for data centers, telecommunications, and critical systems where uninterrupted power is essential, ensuring smooth transitions between power sources.

Specifications last updated 23 July 2026

Voltronic Automatic Transfer Switch ATS-30A full specifications

Electrical

Input Voltage	220/230/240 VAC
Acceptable Input Voltage	180 - 258 VAC
Input Frequency	60 Hz
Maximum Input Current	30 A
Output Voltage	220/230/240 VAC
Maximum Output Current	10 A for IEC-C13 outlets, 16 A for IEC-C19 outlet, 30A for cable gland
Input	2 x cable gland
Output	4 x IEC-C13, 1 x IEC-C19, 1 x cable gland
Communication	USB/RS-232
Transfer time	9-12ms (Typical), 16ms max.

Mechanical

Dimension, D x W x H (mm)	330 x 430 x 44
Net Weight (kgs)	4.5
Net Weight (including accessories) (kgs)	7.5
Weight	4.5 kg

Environmental

Operating Temperature	0-95 % RH @ -5°C- 45°C (non-condensing)

Frequently Asked Questions

The Automatic Transfer Switch operates with an input voltage range of 220/230/240 VAC and an acceptable input voltage range of 180 - 258 VAC. It supports a maximum input current of 30 A and offers a typical transfer time of 9-12ms, with a maximum of 16ms.

The Automatic Transfer Switch is designed to work seamlessly with UPS systems and is compatible with grid power. It does not directly interface with batteries or solar panels.

The dimensions of the Automatic Transfer Switch are 330 x 430 x 44 mm, and it has a net weight of 5 kg, which increases to 8 kg when including accessories.

Installation requires standard electrical connections with two cable-gland inputs and outputs through four IEC-C13 outlets, one IEC-C19 outlet and one cable gland. Ensure proper ventilation and adherence to the operating temperature range.

Voltronic Power typically offers a standard warranty for its products, covering manufacturing defects. Specific warranty terms should be confirmed with the retailer or distributor.

The Automatic Transfer Switch complies with standard certifications, ensuring reliable performance and safety in various applications.

The switch operates efficiently in temperatures ranging from -5°C to 45°C and in humidity levels of 0-95% RH, non-condensing.

Key features include fast transfer times, multiple output options, and robust compatibility with UPS systems, providing reliable power management solutions.

Voltronic Automatic Transfer Switch ATS-30A

Voltronic Automatic Transfer Switch ATS-30A features

Powered by two separately independent

Dual power supply for redundancy

Provides seamless power switch for

Preferred source selection on front

Highly reliability 19" rack design

Built-in intelligent slot for SNMP

Built-in USB and RS-232 communications

About the Voltronic Automatic Transfer Switch ATS-30A

Voltronic Automatic Transfer Switch ATS-30A full specifications

Electrical

Mechanical

Environmental

Frequently Asked Questions

What are the main performance specifications of the Voltronic Power Automatic Transfer Switch?

Is the Automatic Transfer Switch compatible with different battery types or solar panels?

What are the physical specifications of the Automatic Transfer Switch?

What are the installation requirements for the Automatic Transfer Switch?

What warranty does Voltronic Power offer for the Automatic Transfer Switch?

What certifications and standards does the Automatic Transfer Switch comply with?

What are the operating conditions for the Automatic Transfer Switch?

What are the key features and benefits of the Automatic Transfer Switch?
