Voltronic Power Axpert VM III TWIN IP52 4.5K Off-Grid Solar Inverter

Voltronic Axpert VM III TWIN IP52 4.5K Off-Grid Solar Inverter

The Axpert VM III TWIN IP52 40A Axpert VM III TWIN IP52 4.5K is an off-grid solar inverter rated Axpert VM III TWIN IP52 4.5K.

  • Rated Power: 4500VA/4500W
  • Selectable Voltage Range: 170-280 VAC (For Personal Computers)
AED 1incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

About the Voltronic Axpert VM III TWIN IP52 4.5K Off-Grid Solar Inverter

The Axpert VM III TWIN IP52 40A Axpert VM III TWIN IP52 4.5K is an off-grid solar inverter rated Axpert VM III TWIN IP52 4.5K. Every figure on this page is read from the manufacturer's manual for the Axpert VM III TWIN IP52 40A series.

Specifications last updated 18 August 2026

Voltronic Axpert VM III TWIN IP52 4.5K Off-Grid Solar Inverter full specifications

Electrical

Rated Power4500VA/4500W
Selectable Voltage Range170-280 VAC (For Personal Computers)
AC Voltage Regulation (Batt. Mode)230VAC ± 5%
Efficiency (Peak)93%
Maximum PV Array Power6000W
Maximum Solar Charge Current120A
Maximum AC Charge Current100A
Maximum Charge Current120A
Communication InterfaceUSB/RS232/RS485/WiFi/Dry-contact
Ingress ProtectionIP52
Surge Power9000VA
Maximum PV Input Current40A
Transfer Time10 ms (For Personal 20 ms (For Home
MPP Range @ Operating Voltage60 450
Floating Charge Voltage27 VDC
WaveformPure sine wave
Maximum PV Array Open Circuit Voltage500 VDC
Solar Charger typeMPPT

Environmental

Humidity5% to 95%
Operating Temperature-10°C to 50°C
Storage Temperature-15°C to 60°C
