Built-in maximum power point tracking
Built-in maximum power point tracking (MPPT) algorithm
VFDModel VOLTRONIC-IMASTER-SP
Voltronic iMaster Solar Pump Inverter
AED 3,500incl. VAT
Out of stock
- Collect your order from our stores in Dubai and Riyadh, or in your own country in our other markets.
- 2-year warranty
- Defective items can be returned within 30 days of receipt; change-of-mind returns are not accepted.
- Full Specifications
- Download datasheet (PDF)
- Input Voltage
- 220-440 VAC
- Rated Frequency
- 50/60 Hz
- Frequency Range
- ±5% (47.5 ~ 63Hz)
Description
Discover the iMaster Solar Pump Inverter by Voltronic Power with AC input voltage 220V-240V and DC voltage 450VDC for efficient solar pumping.
Voltronic iMaster Solar Pump Inverter full specifications
Key specifications
| Input Voltage | AC,1PH,220V(-15%) ~ 240V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) |
|---|---|
| Input DC Voltage | 450VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC |
| Recommended VOC Voltage Range | 360 ~ 430VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC / 550 ~ 750VDC |
| Recommended MPPT | 250 ~ 350VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC |
| Voltage Range | 160 ~ 450VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) / 300 ~ 900VDC (parameter adjustable) |
|---|---|
| Output Voltage | 0- Input Voltage |
| Maximum Output Frequency | 0.1 ~ 500Hz |
| Control Mode | Open-loop vector control (SVC) ; V/F control |
All specifications (18)
Electrical(3)
| Starting Torque | 0.5Hz/150% (SVC) |
|---|---|
| Speed Control Accuracy | ±0.5% (SVC) |
| Communication Port | RS-485 |
Mechanical(2)
| Dimensions (mm) | PC10-0.75G-S2: 67.3 x 157.5 x 171 / PC10-1.5G-S2: 85 x 184 x 197.5 / PC10-2.2G-S2: 106 x 233 x 245 / PC10-4.0G-S2: 106 x 233 x 245 / PC10-5.5G-S2: 106 x 233 x 245 / PC10-0.75G-T4: 67.3 x 157.5 x 171 / PC10-1.5G-T4: 85 x 184 x 197.5 / PC10-2.2G-T4: 106 x 233 x 245 / PC10-3.7G-T4: 106 x 233 x 245 / PC10-5.5G-T4: 106 x 233 x 245 / PC10-7.5G-T4: 106 x 233 x 245 / PC10-11G-T4: 147 x 298 x 310 / PC10-15G-T4: 147 x 298 x 310 / PC10-18.5G-T4: 147 x 298 x 310 / PC10-22G-T4: 147 x 298 x 310 / PC10-30G-T4: 260 x 433.5 x 450 / PC10-37G-T4: 260 x 433.5 x 450 |
|---|---|
| Weight (kg) | PC10-0.75G-S2: 1 / PC10-1.5G-S2: 1.5 / PC10-2.2G-S2: 3.5 / PC10-4.0G-S2: 3.5 / PC10-5.5G-S2: 3.5 / PC10-0.75G-T4: 1 / PC10-1.5G-T4: 1.5 / PC10-2.2G-T4: 3.5 / PC10-3.7G-T4: 3.5 / PC10-5.5G-T4: 3.5 / PC10-7.5G-T4: 3.5 / PC10-11G-T4: 5.5 / PC10-15G-T4: 5.5 / PC10-18.5G-T4: 5.5 / PC10-22G-T4: 5.5 / PC10-30G-T4: 15.5 / PC10-37G-T4: 15.5 |
Environmental(5)
| Protective Function | Power-on motor short circuit detection, output phase loss protection, overcurrent protection, overvoltage protection, undervoltage protection, overheat protection, overload protection, underload protection, weak light protection, etc. |
|---|---|
| Storage Temperature | -20°C ~ 60°C |
| Operation Temperature | -10°C ~ 50°C (If temperature is higher than 40°C, the output capacity will be derated 1% per 1°C increase) |
| Operation Humidity | < 95% RH |
| Noise Level | 50dBA max (0.75G-7.5G) / 65dBA max (11G-37G) |
Certifications(3)
- IEC 61800-5-1
- IEC 61800-3(C3)
- RoHS Compliant
Comparisons featuring this product
Voltronic iMaster Solar Pump Inverter features
Strong anti-interference capabilities
V/F Control, Sensor-less Vector Control
V/F Control, Sensor-less Vector Control (SVC) and Feedback Vector Control (FVC) selectable
Automatic torque boost and slip
Automatic torque boost and slip compensation
Built-in RS-485 MODBUS communication
Supports an external keypad
About the Voltronic iMaster Solar Pump Inverter
The Voltronic iMaster Solar Pump Inverter is a Variable Frequency Drive with a maximum output frequency of 0.1 ~ 500 Hz, making it a dependable choice for controlling motor speed in pumping and industrial applications. It accepts an operating voltage range of 360 ~ 430 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC. The unit measures PC10-0.75G-S2: 67.3 x 157.5 x 171 / PC10-1.5G-S2: 85 x 184 x 197.5 / PC10-2.2G-S2: 106 x 233 x 245 / PC10-4.0G-S2: 106 x 233 x 245 / PC10-5.5G-S2: 106 x 233 x 245 / PC10-0.75G-T4: 67.3 x 157.5 x 171 / PC10-1.5G-T4: 85 x 184 x 197.5 / PC10-2.2G-T4: 106 x 233 x 245 / PC10-3.7G-T4: 106 x 233 x 245 / PC10-5.5G-T4: 106 x 233 x 245 / PC10-7.5G-T4: 106 x 233 x 245 / PC10-11G-T4: 147 x 298 x 310 / PC10-15G-T4: 147 x 298 x 310 / PC10-18.5G-T4: 147 x 298 x 310 / PC10-22G-T4: 147 x 298 x 310 / PC10-30G-T4: 260 x 433.5 x 450 / PC10-37G-T4: 260 x 433.5 x 450 and weighs PC10-0.75G-S2: 1 / PC10-1.5G-S2: 1.5 / PC10-2.2G-S2: 3.5 / PC10-4.0G-S2: 3.5 / PC10-5.5G-S2: 3.5 / PC10-0.75G-T4: 1 / PC10-1.5G-T4: 1.5 / PC10-2.2G-T4: 3.5 / PC10-3.7G-T4: 3.5 / PC10-5.5G-T4: 3.5 / PC10-7.5G-T4: 3.5 / PC10-11G-T4: 5.5 / PC10-15G-T4: 5.5 / PC10-18.5G-T4: 5.5 / PC10-22G-T4: 5.5 / PC10-30G-T4: 15.5 / PC10-37G-T4: 15.5. It is rated to operate across -10°C ~ 50°C (If temperature is higher than 40°C, the output capacity will be derated 1% per 1°C increase), with a humidity tolerance of < 95% RH. Monitoring and control are available over RS-485. The iMaster Solar Pump Inverter is certified to IEC 61800-5-1, IEC 61800-3(C3) and RoHS Compliant and is backed by a 2-year manufacturer warranty from Voltronic Power. Its published specifications also list Input Voltage of AC,1PH,220V(-15%) ~ 240V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%) / AC,3PH,380V(-15%) ~ 440V(+10%), Input DC Voltage of 450VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC / 900VDC and Recommended MPPT of 250 ~ 350VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC / 450 ~ 600VDC.
Specifications last updated 27 March 2026
Where to collect your order
AGS International General Trading LLC
11 25th Street, Naif, Deira, Dubai, UAE
Mon–Sat, 09:30–21:00
Open in Google Maps — AGS International General Trading LLCAbduljalil Chhada Auto Spare Parts Trading LLC
Partner store that holds our stock
16 33rd Street, Naif, Deira, Dubai, UAE
Mon–Sat, 09:30–19:30
Open in Google Maps — Abduljalil Chhada Auto Spare Parts Trading LLCAGS International
Omar Al Moukhtar, Thulaim, Riyadh, Saudi Arabia
Sat–Thu, 08:00–12:30 and 16:00–21:00
Open in Google Maps — AGS International
Frequently Asked Questions
What voltage range does the iMaster Solar Pump Inverter accept?
The iMaster Solar Pump Inverter accepts an input voltage range of 360 ~ 430 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC / 550 ~ 750 VDC.
What are the physical dimensions and weight of the iMaster Solar Pump Inverter?
The iMaster Solar Pump Inverter measures PC10-0.75G-S2: 67.3 x 157.5 x 171 / PC10-1.5G-S2: 85 x 184 x 197.5 / PC10-2.2G-S2: 106 x 233 x 245 / PC10-4.0G-S2: 106 x 233 x 245 / PC10-5.5G-S2: 106 x 233 x 245 / PC10-0.75G-T4: 67.3 x 157.5 x 171 / PC10-1.5G-T4: 85 x 184 x 197.5 / PC10-2.2G-T4: 106 x 233 x 245 / PC10-3.7G-T4: 106 x 233 x 245 / PC10-5.5G-T4: 106 x 233 x 245 / PC10-7.5G-T4: 106 x 233 x 245 / PC10-11G-T4: 147 x 298 x 310 / PC10-15G-T4: 147 x 298 x 310 / PC10-18.5G-T4: 147 x 298 x 310 / PC10-22G-T4: 147 x 298 x 310 / PC10-30G-T4: 260 x 433.5 x 450 / PC10-37G-T4: 260 x 433.5 x 450 and weighs PC10-0.75G-S2: 1 / PC10-1.5G-S2: 1.5 / PC10-2.2G-S2: 3.5 / PC10-4.0G-S2: 3.5 / PC10-5.5G-S2: 3.5 / PC10-0.75G-T4: 1 / PC10-1.5G-T4: 1.5 / PC10-2.2G-T4: 3.5 / PC10-3.7G-T4: 3.5 / PC10-5.5G-T4: 3.5 / PC10-7.5G-T4: 3.5 / PC10-11G-T4: 5.5 / PC10-15G-T4: 5.5 / PC10-18.5G-T4: 5.5 / PC10-22G-T4: 5.5 / PC10-30G-T4: 15.5 / PC10-37G-T4: 15.5.
What is the operating temperature range of the iMaster Solar Pump Inverter?
The iMaster Solar Pump Inverter operates across -10°C ~ 50°C (If temperature is higher than 40°C, the output capacity will be derated 1% per 1°C increase) and a humidity range of < 95% RH.
What communication options does the iMaster Solar Pump Inverter offer?
The iMaster Solar Pump Inverter offers RS-485 connectivity for monitoring and control.
How loud is the iMaster Solar Pump Inverter during operation?
The iMaster Solar Pump Inverter has a noise level of 50dBA max (0.75G-7.5G) / 65dBA max (11G-37G) during operation.
How does the iMaster Solar Pump Inverter control motor speed?
The iMaster Solar Pump Inverter offers a control mode of Open-loop vector control (SVC), a starting torque of 0.5 Hz/150% (SVC) and a speed control accuracy of ±0.5% (SVC).
What certifications does the iMaster Solar Pump Inverter have?
The iMaster Solar Pump Inverter is certified to IEC 61800-5-1, IEC 61800-3(C3) and RoHS Compliant, meeting recognised international standards for safety and performance.
What warranty coverage is available for the iMaster Solar Pump Inverter?
The iMaster Solar Pump Inverter is backed by a 2-year manufacturer warranty from Voltronic Power.
