Voltronic Power Axpert MAX III 11KW Off-Grid Solar Inverter

Voltronic Axpert MAX III 11KW Off-Grid Solar Inverter

The Axpert MAX III 11KW is an off-grid solar inverter rated Axpert MAX III 11KW.

  • Parallel Capability: YES, 6 units
  • Selectable Voltage Range: 170-280 VAC (For Personal Computers)
AED 1incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

About the Voltronic Axpert MAX III 11KW Off-Grid Solar Inverter

The Axpert MAX III 11KW is an off-grid solar inverter rated Axpert MAX III 11KW. Every figure on this page is read from the manufacturer's manual for the Axpert MAX III series.

Specifications last updated 18 August 2026

Voltronic Axpert MAX III 11KW Off-Grid Solar Inverter full specifications

Electrical

Parallel CapabilityYES, 6 units
Selectable Voltage Range170-280 VAC (For Personal Computers)
AC Voltage Regulation (Batt. Mode)230VAC ± 5%
Efficiency (Peak)93%
No Load Power Consumption<75W
Maximum PV Array Power12000W (6000W x 2)
Maximum Charge Current150A
Communication InterfaceUSB/RS232/RS485/Wifi/Dry-contact
Compliance SafetyIEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, 61000-3-12
Rated Inverter Power11000VA/11000W
Surge Power22000VA
Maximum PV Input Current27A x 2 (MAX. 40A)
Maximum Solar Charge Current150A
Maximum AC Charge Current150A
Floating Charge Voltage54 VDC
MPP Range @ Operating Voltage90 ~ 450 VDC
Maximum PV Array Open Circuit Voltage500 VDC
WaveformPure sine wave
Transfer Time15 ms (For Personal Computers), 20 ms (For Home Appliances)
DC Voltage12 VDC ± 5%, 100W
Solar Charger typeMPPT
Frequency Range50 Hz/60 Hz (Auto sensing)
Battery Voltage48 VDC
Overcharge Protection66 VDC

Mechanical

Net Weight (kgs)28.5

Environmental

Humidity5% to 95%
Operating Temperature-10°C to 50°C
Storage Temperature-15°C to 60°C
