Voltronic Power SCC MPPT SCC-MPPT 3KW Solar Charge Controller

Voltronic SCC-MPPT 3KW Solar Charge Controller

The SCC MPPT SCC-MPPT 3KW is a solar charge controller rated SCC-MPPT 3KW.

  • Maximum Current: 17A
  • Maximum Charging Current: 20A
  • Maximum Efficiency: 98%
AED 1incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

About the Voltronic SCC-MPPT 3KW Solar Charge Controller

The SCC MPPT SCC-MPPT 3KW is a solar charge controller rated SCC-MPPT 3KW. Every figure on this page is read from the manufacturer's manual for the SCC MPPT series.

Specifications last updated 18 August 2026

Voltronic SCC-MPPT 3KW Solar Charge Controller full specifications

Electrical

Maximum Current17A
Maximum Charging Current20A
Maximum Efficiency98%
Overload Protection> 110% audible alarm
Overcharge ProtectionYes
IP ProtectionIP 43
Maximum PV Array Power3200W
Connected Battery TypeSealed lead acid, AGM or Gel
Maximum PV Array Open Circuit Voltage145VDC
Advancing Power8
LCD PanelLCD panel indicating solar power, load level, battery voltage/capacity, charging current, and fault conditions
LED DisplayThree indicators for solar, charging, and load status
Maximum Solar Module Open Circuit Voltage50 V
Maximum Solar Module Power300 W
Vented14.3 V
AppliancesPower Consumption (W)

Mechanical

Dimension (DxWxH mm)135 x 170 x 57.5

Environmental

HumidityIP 31
Storage Temperature-15°C to 60°C
Operating Temperature0°C to 55°C
Altitude0 ~ 3000 m
