Voltronic ESS510 5.5KW Solar Inverter

Name: Voltronic ESS510 5.5KW Solar Inverter
Brand: Voltronic Power
SKU: ESS510-5.5KW
Price: 1 AED
Availability: InStock

The ESS510 5.5KW is a solar inverter rated 5.5KW. Every figure on this page is read from the manufacturer's manual for the ESS510 series.

1 AEDincl. VAT

Overview

The ESS510 5.5KW is a solar inverter rated 5.5KW. Every figure on this page is read from the manufacturer's manual for the ESS510 series.

Max. Output Current	23.9A*
Efficiency (DC to AC)	208/220/230/240 VAC
Capacity	4800Wh 48VDC 52.5V
Max Continuous Discharging Current	120A
Protection	BMS, Breaker
Charge Current	30A
Inner Resistance	<20m ohm
Number of MPP Trackers / Maximum Input Current	2 / 2 x 13 A
Maximum PV Input Power	6500W
Nominal DC Voltage / Maximum DC Voltage	360 VDC / 500 VDC
Start-up Voltage / Initial Feeding Voltage	116 VDC / 150 VDC
Output Voltage Range	184 - 264.5 VAC*
Maximum Conversion Efficiency (DC/AC)	96%
European Efficiency @ Vnominal	95%
Acceptable Input Voltage Range	170 -280 VAC
Maximum AC Input Current	40 A
Maximum Charging Current	100 A
Nominal Voltage	51.2VDC
Full Charge Voltage (FC)	56V
Full Discharge Voltage (FD)	42V
Max Discharging Current	192A at 1min
Maximum Charge Current	50A (0.5C)
Compliance Safety	IEC/EN 62109-1/-2, IEC 62040-1, EN 61000-6-4, EN IEC 61000-6-2, EN IEC 61000-3-11, EN 61000-3-12, IEC 61727, IEC 62116, G99, NRS 097-2-1, EN 50549-1
Battery Module Compliance Safety	IEC 62619, EN 61000-6-3, EN 61000-6-1, UKCA, UN38.3
