Voltronic Power Solar Online UPS

Voltronic Solar Online UPS

Discover Voltronic Power's Solar Online UPS with 220/230/240VAC output and ±1% voltage regulation for reliable power solutions.

  • Voltage: 220-240 VAC
  • Voltage Range: 110-280 VAC
  • Power Factor: >= 0.95
3,500 AEDincl. VAT
Full Specifications

Features

SBU (Solar, Battery, Utility) priority

SBU (Solar, Battery, Utility) priority smart management

Built-in 1KW or 1.5KW MPPT

Built-in 1KW or 1.5KW MPPT solar charger

True double-conversion

Input power factor correction

Wide input voltage (110V-280V)

Converter mode available

ECO mode for energy saving

Generator compatible

Optional Isolation transformer for full

Optional Isolation transformer for full isolation and complete common mode noise rejection

Comprehensive display allows easy monitoring

Comprehensive display allows easy monitoring and access of UPS & solar energy status

Overview

Introducing the Voltronic Power Solar Online UPS, a cutting-edge solution for uninterrupted power supply. With a nominal voltage of 220/230/240VAC and precise voltage regulation of ±1%, this UPS ensures optimal performance and reliability. Ideal for solar energy systems, data centers, and critical infrastructure, the Solar Online UPS provides seamless power backup and protection against voltage fluctuations.

Full specifications

Electrical

Nominal Voltage220/230/240VAC
Input Voltage Range110-280VAC
Frequency Range40Hz - 70Hz
Power Factor≥ 0.95 @ Nominal Voltage (100% load)
Output Voltage220/230/240VAC
Voltage Regulation± 1%
Frequency Range (Synchronized Range)47 - 53Hz or 57 - 63Hz
Frequency Range (Batt. Mode)50Hz or 60Hz ± 0.1Hz
Current Crest Ratio3:1
Harmonic Distortion≤ 3 % THD (Linear Load) ; ≤ 6 % THD (Non-linear Load)
Transfer Time0 ms
Waveform (Batt. Mode)Pure Sinewave
AC Mode88% / 89% / 90%
Battery Voltage36VDC / 72VDC / 72VDC
Charging Current (max.)1A/2A/4A/6A (Default), adjustable by internal jumper
Charging Voltage41.0VDC ± 1% / 82.1VDC ± 1% / 82.1VDC ± 1%
Solar Charger TypeMPPT
Maximum PV Array Open Circuit Voltage145VDC
Maximum PV Array Power1000W / 1500W / 1500W
MPP Range @ Operating Voltage40VDC - 115VDC / 90VDC - 115VDC / 90VDC - 115VDC
Maximum Solar AC Mode20A
Charge Current Battery Mode15A
Smart RS-232 / USBSupports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8/10, Linux and MAC
Optional SNMPPower management from SNMP manager and web browser

Mechanical

Dimension, D x W x H (mm)282 x 145 x 332 / 400 x 145 x 332 / 400 x 145 x 332
Net Weight (kgs)7.6 / 12 / 12.3
Weight7.6 / 12 / 12.3

Environmental

Humidity20-90% RH @ 0-50°C (Non-condensing)
Noise LevelLess than 50dB @ 1 Meter
